GWR Route: Banbury to Wolverhampton

Leamington Shed: gwrls2044

A 1925 map showing the layout of Leamington shed and the carriage sidings which were adjacent to the line to Paddington

A 1925 map showing the layout of Leamington shed and the carriage sidings which were adjacent to the line to Paddington. The former LNWR branch between Leamington and Rugby passes to the other side of the shed which allows for a junction between the two companies to be made. The signal box controlling the junction was originally named East Junction Signal Box but later renamed South Junction Signal Box which it carried until it was closed on 19th July 1966.
