Washwood Heath Sidings: mrwhg627b

Close up showing the 1930 built Washwood Heath Sidings No 5 Signal Box which had the first four roads under its direct control

Close up of image 'mrwhg627' showing the 1930 built Washwood Heath Sidings No 5 Signal Box which had the first four roads under its direct control out of the twenty-five available on up sidings. The line passing to the left of the signal box was listed on a diagram in Midland Record No 26 as the, 'Running Road to Dugout', whilst the other three were described as 'Transfer Road to Dugout', 'Lawley Street Traffic' and 'Brake Vans'. To the right of the No 5 box a fifth line ran towards Washwood Heath Siding No 6 Signal Box where under its direction the sidings fanned out into the remaining twenty-one sidings.
