LMS Route: Evesham to Birmingham

Kings Norton Station: mrkn797

View of the track layout at the station where Camp Hill and West Suburban lines merged with the four lines to Barnt Green. The lines are from left to right, up goods, up main, down main and down goods. At the four platforms, seen beyond the passenger footbridge, these lines had become, up West Suburban, down West Suburban, up Camp Hill and down Camp Hill. On the left the up goods line was sectioned so that vehicles or trains could be stabled in the section between the crossover bottom left and the up West Suburban platform.
